Hydraulics | 20MJ-16MORB Straight Adapter | 6400-20-16-O

Hydraulics | 20MJ-16MORB Straight Adapter | 6400-20-16-O

THREAD B1 TYPE MALE JIC SAE 37 DEGREE FLARE
THREAD B1 SIZE 1-5/8-12
THREAD B1 DRILL IN 1.078
THREAD B1 SPECIFICATION SAE J514
THREAD B2 TYPE MALE SAE O-RING BOSS
THREAD B2 SIZE 1-5/16-12
THREAD B2 DRILL IN 0.844
THREAD B2 SPECIFICATION SAE J514
BODY HEX IN 1.688
OVERALL LENGTH L IN 2.330
SHAPE STRAIGHT
BODY MATERIAL STEEL
RAW MATERIAL TYPE STRAIGHT STEEL
PLATING CR3
O-RING / SEAL MATERIAL NBR
WEIGHT LBS 0.7053
MAXIMUM DYNAMIC PRESSURE PSI 4,000
CALIFORNIA RESIDENTS PROP-65 WARNING
CUBIC INCH SPACE L X W X H 6.639
$2.83

Original: $8.10

-65%
Hydraulics | 20MJ-16MORB Straight Adapter | 6400-20-16-O—

$8.10

$2.83

Product Information

Shipping & Returns

Description

THREAD B1 TYPE MALE JIC SAE 37 DEGREE FLARE
THREAD B1 SIZE 1-5/8-12
THREAD B1 DRILL IN 1.078
THREAD B1 SPECIFICATION SAE J514
THREAD B2 TYPE MALE SAE O-RING BOSS
THREAD B2 SIZE 1-5/16-12
THREAD B2 DRILL IN 0.844
THREAD B2 SPECIFICATION SAE J514
BODY HEX IN 1.688
OVERALL LENGTH L IN 2.330
SHAPE STRAIGHT
BODY MATERIAL STEEL
RAW MATERIAL TYPE STRAIGHT STEEL
PLATING CR3
O-RING / SEAL MATERIAL NBR
WEIGHT LBS 0.7053
MAXIMUM DYNAMIC PRESSURE PSI 4,000
CALIFORNIA RESIDENTS PROP-65 WARNING
CUBIC INCH SPACE L X W X H 6.639
