Hydraulics | 08FBSPP Cap | 9644-C-08
| THREAD TYPE B1 | FEMALE BSPP SWIVEL |
| THREAD SIZE B1 | 1/2-14 |
| THREAD SPECIFICATION B1 | ISO 1179, ISO 8434-6, BS 5200 |
| BODY HEX (MM) | 27.0 |
| OVERALL LENGTH L1 (MM) | 25.45 |
| OVERALL LENGTH L2 (MM) | 18.6 |
| SHAPE | STRAIGHT |
| BODY MATERIAL | STEEL |
| RAW MATERIAL TYPE | STRAIGHT STEEL |
| PLATING | CR3 |
| WEIGHT (LBS) | 0.181 |
| MAXIMUM DYNAMIC PRESSURE (PSI) | 2,900 |
| CALIFORNIA RESIDENTS | PROP-65 WARNING |
| CUBIC INCH SPACE (L X W X H) | 1.132 |
$6.44
Hydraulics | 08FBSPP Cap | 9644-C-08—
$6.44
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
| THREAD TYPE B1 | FEMALE BSPP SWIVEL |
| THREAD SIZE B1 | 1/2-14 |
| THREAD SPECIFICATION B1 | ISO 1179, ISO 8434-6, BS 5200 |
| BODY HEX (MM) | 27.0 |
| OVERALL LENGTH L1 (MM) | 25.45 |
| OVERALL LENGTH L2 (MM) | 18.6 |
| SHAPE | STRAIGHT |
| BODY MATERIAL | STEEL |
| RAW MATERIAL TYPE | STRAIGHT STEEL |
| PLATING | CR3 |
| WEIGHT (LBS) | 0.181 |
| MAXIMUM DYNAMIC PRESSURE (PSI) | 2,900 |
| CALIFORNIA RESIDENTS | PROP-65 WARNING |
| CUBIC INCH SPACE (L X W X H) | 1.132 |
